Video: Rotel A10 MKII Integrated Amplifier
The A10MKII Integrated Amplifier brings to you the ideal amalgamation of power and style for the music lover seeking to boost their listening experience. Built around a linear power supply featuring a massive Rotel-built toroidal power transformer, the
A10MKII packs a punch with an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher power into more challenging loudspeakers.
Warranty
2-year manufacturer's warranty
Rotel A10 MKII Key Features
- 2 x 50 Watts of robust Class AB power, 8 Ohms
- Moving magnet phono stage input for turntable connection
- Texas Instruments premium 32-bit/384kHz Digital to Analog Converter
- Bluetooth with aptXTM HD and AAC
- Includes remote control
Benefits of Rotel A10 MKII Integrated Amplifier
Superior Level of Acoustic Performance
Exclusive Rotel power supply innovations and critical circuit layout provide physical and electrical separation to lower the noise floor and increase musical dynamics. The A10MKII’s multi-tap transformer delivers power to sensitive low-voltage circuits and the high current amplifier output stage independently, isolating the signal path from noise and reducing unwanted distortion. This sound-first design supports fast transients and delivers an expressive, open musical performance.
Effortless Control of the Audio
All analog sources are welcome, with three line-level RCA inputs, and a Moving Magnet compatible Phono stage provided for vinyl lovers. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions.
A Pleasure to operate
An intuitive front panel layout includes rotary Bass, Treble, and Balance controls making the A10MKII a joy to use up close, while the included IR remote control, and a motorized analog volume controller extend ease of use to the listening seat. User friendly features such as a detachable IEC power cord, two 12V trigger outputs, heavy 5-way speaker binding posts, and auto power-off functions ensure compatibility with any installation.
Where to buy:
Buy the Rotel A10 MKII Integrated Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai & all across India. Enjoy expert, prompt & courteous customer service from the Ooberpad team. We will help you choose better & give you all the support you need to take the right buying decision in India.
Technical Specifications of Rotel A10 MKII Integrated Amplifier
| Brand & Model # | Rotel A10 MKII |
| Continuous Power Output |
50 Watts / ch (8 Ohms)
|
| Total Harmonic Distortion |
<0.03% |
| Intermodulation Distortion (60Hz:7kHz, 4:1) | <0.03% |
| Frequency Response |
Phono input 20 Hz - 20k Hz, -0.5 dB, +0.3 dB
Line Level Inputs 10 Hz - 100k Hz, -0.5 dB, +0.05 dB |
|
S/N Ratio (IHF "A" Weighted) |
Line Level Inputs: 100dB
Phono Input: 85dB
|
| Damping Factor (20 - 20,000 Hz, 8 Ohms) | 120 |
|
Input Sensitivity |
Phono input 1.5 mV / 43k Ohms
Line Level Inputs 120 mV / 45k Ohms |
|
Input Overload |
Phono input 50 mV
Line Level Inputs 4 V |
| Tone Controls - Bass / Treble | ± 6 dB at 100 Hz / 10k Hz |
|
Signal to Noise Ratio (IHF “A” weighted) |
Phono input 85 dB
Line Level Inputs 90 dB |
|
Power Requirements |
USA 120 V, 60 Hz Europe 230 V, 50 Hz |
| Power Consumption | 150 Watts |
|
Standby Power Consumption |
< 0.5 Watts
|
|
BTU (4 Ohms, 1/8 power) |
450 BTU/h |
|
Dimensions (WxHxD) |
430 x 73 x 347 mm 17” x 2 7/8” x 13 5/8” |
|
Front Panel Height |
60 mm / 2 3/8” |
|
Net Weight |
6.6 kg, 14.5 lbs. |
|
Finish |
Black and Silver |
Video: Rotel A10 MKII Integrated Amplifier
The A10MKII Integrated Amplifier brings to you the ideal amalgamation of power and style for the music lover seeking to boost their listening experience. Built around a linear power supply featuring a massive Rotel-built toroidal power transformer, the
A10MKII packs a punch with an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher power into more challenging loudspeakers.
Warranty
2-year manufacturer's warranty
Rotel A10 MKII Key Features
- 2 x 50 Watts of robust Class AB power, 8 Ohms
- Moving magnet phono stage input for turntable connection
- Texas Instruments premium 32-bit/384kHz Digital to Analog Converter
- Bluetooth with aptXTM HD and AAC
- Includes remote control
Benefits of Rotel A10 MKII Integrated Amplifier
Superior Level of Acoustic Performance
Exclusive Rotel power supply innovations and critical circuit layout provide physical and electrical separation to lower the noise floor and increase musical dynamics. The A10MKII’s multi-tap transformer delivers power to sensitive low-voltage circuits and the high current amplifier output stage independently, isolating the signal path from noise and reducing unwanted distortion. This sound-first design supports fast transients and delivers an expressive, open musical performance.
Effortless Control of the Audio
All analog sources are welcome, with three line-level RCA inputs, and a Moving Magnet compatible Phono stage provided for vinyl lovers. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions.
A Pleasure to operate
An intuitive front panel layout includes rotary Bass, Treble, and Balance controls making the A10MKII a joy to use up close, while the included IR remote control, and a motorized analog volume controller extend ease of use to the listening seat. User friendly features such as a detachable IEC power cord, two 12V trigger outputs, heavy 5-way speaker binding posts, and auto power-off functions ensure compatibility with any installation.
Where to buy:
Buy the Rotel A10 MKII Integrated Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai & all across India. Enjoy expert, prompt & courteous customer service from the Ooberpad team. We will help you choose better & give you all the support you need to take the right buying decision in India.
Technical Specifications of Rotel A10 MKII Integrated Amplifier
| Brand & Model # | Rotel A10 MKII |
| Continuous Power Output |
50 Watts / ch (8 Ohms)
|
| Total Harmonic Distortion |
<0.03% |
| Intermodulation Distortion (60Hz:7kHz, 4:1) | <0.03% |
| Frequency Response |
Phono input 20 Hz - 20k Hz, -0.5 dB, +0.3 dB
Line Level Inputs 10 Hz - 100k Hz, -0.5 dB, +0.05 dB |
|
S/N Ratio (IHF "A" Weighted) |
Line Level Inputs: 100dB
Phono Input: 85dB
|
| Damping Factor (20 - 20,000 Hz, 8 Ohms) | 120 |
|
Input Sensitivity |
Phono input 1.5 mV / 43k Ohms
Line Level Inputs 120 mV / 45k Ohms |
|
Input Overload |
Phono input 50 mV
Line Level Inputs 4 V |
| Tone Controls - Bass / Treble | ± 6 dB at 100 Hz / 10k Hz |
|
Signal to Noise Ratio (IHF “A” weighted) |
Phono input 85 dB
Line Level Inputs 90 dB |
|
Power Requirements |
USA 120 V, 60 Hz Europe 230 V, 50 Hz |
| Power Consumption | 150 Watts |
|
Standby Power Consumption |
< 0.5 Watts
|
|
BTU (4 Ohms, 1/8 power) |
450 BTU/h |
|
Dimensions (WxHxD) |
430 x 73 x 347 mm 17” x 2 7/8” x 13 5/8” |
|
Front Panel Height |
60 mm / 2 3/8” |
|
Net Weight |
6.6 kg, 14.5 lbs. |
|
Finish |
Black and Silver |
Rotel A10 MKII Integrated Amplifier
- Regular price
- ₹ 72,900.00
- Sale price
- ₹ 72,900.00
- Regular price
-
₹ 72,900.00
Country of Origin: Japan
