Ooberpad presents the dynamic Parasound Halo P 6 2.1 Channel Preamplifier & DAC. This advanced 2.1 channel preamplifier has been meticulously designed for the best in class performance for serious two-channel music listening and ease of integration with a surround sound system. Based on the high-performance preamplifier section of the brand new Halo HINT 6 integrated amplifier, the P 6 offers a wide array of extensive features as compared to its predecessor, the Halo P 5, along with improved sound and an unrivalled ease-of-use.
Geared up for today's hi-res digital music files and excelling with vinyl playback, too, the P 6 packs an advanced ESS Sabre32 Reference DAC to decode a wide range of digital music files via its digital inputs. It also includes a top-of-the-line quality built-in MM/MC phono stage with three-position load/cartridge selector switch as well as a high-current headphone stage built around the top grade Texas Instruments TPA6120A headphone amplifier chipset.
The breakthrough feature pack comprises of Burr-Brown volume control with easy-to-read front panel display. It also adds an upgraded USB receiver with plug-and-play operationality for Windows and Mac, a second optical input, increased phono gain, greater channel separation, and some highly appealing refinements to its appearance as opposed to the P 5 and original model Halo Integrated. Among the other new features is a Favorite volume memory with the remote control button, increased phono stage gain for lower output cartridges, enhanced channel separation and balance tracking, a ball-bearing supported solid aluminium volume knob and a programable default turn on volume setting.
Warranty
1-year manufacturer's warranty
Key Features:
- ESS Sabre32 Reference DAC replaces the original Burr-Brown DAC
- USB input is now capable of DSD & 384kHz/32-bit PCM (up from 96Khz/24-bit)
- Burr Brown analog resistor ladder volume control
- Dimmable front panel volume display
- Upgraded USB receiver with "plug and play" operation with Windows 10
- An additional optical input (2 total)
- Ball bearing supported solid aluminum volume knob
- Programable default turn on volume setting
- Favorite volume memory with remote control button
- Increased phono stage gain for lower output cartridges
- Improved Left/Right channel separation and balance tracking
- Sand blasted metal end caps replace plastic end caps on the P 5
- Updated cosmetics with subtle gold highlights
- ESS Sabre32 Reference DAC (ES9018K2M)
- Asynchronous USB 2.0 supports PCM up to 384kHz/32-bit
- USB input decodes Native DSD64, DSD128, DSD256 and DoP DSD
- Coax and optical inputs accept PCM up to 192kHz/24-bit
- Analog bass management with high & low pass crossovers
- Home theater bypass input for surround sound integration
- Front panel subwoofer level control
- Dedicated high current headphone amplifier (TI TPA6120)
- Phono input for MM, MC and MI with 100 Ω or 47k Ω load
- Front panel Aux input with automatic +12 dB gain stage
- 5 pairs RCA line level Analog inputs
- 1 pair XLR balanced Analog input
- Balanced XLR and RCA left and right preamp outputs
- 1 balanced XLR and 2 RCA subwoofer outputs
- Bass & treble controls with relay bypass from remote or front panel
- Rear panel IR input and IR loop output jacks
- 12 Volt trigger output
- Back-lit remote control with discrete buttons
- 0.5w standby power consumption meets Energy Star & EU specs"
Where to buy?
Buy Parasound Halo P 6 2.1 Channel Preamplifier & DAC online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.
Technical Specifications of Parasound Halo P 6 2.1 Channel Preamplifier & DAC:
| Brand & Model # | Parasound Halo P 6 |
| Frequency Response |
10 Hz - 100 kHz, +0/-3 dB 20 Hz - 20 kHz, +0/-0.5 dB |
| Total Harmonic Distortion (THD) |
< 0.01 % |
| Interchannel Crosstalk |
> 70 dB at 20 kHz > 78 dB at 1 kHz |
| Preamplifier Stage Input Sensitivity | 300 mV in for 1 V Total Gain: 10 dB Max Output: 7.5V |
|
S/N Ratio - Line Inputs 1- 5 |
> 108 dB (shorted, IHF A-weighted) > 88 dB (shorted, unweighted) |
| S/N Ratio - DAC Inputs |
> 108 dB (IHF A-weighted) > 88 dB (unweighted) |
| S/N Ratio - Phono Input |
MM > 80 dB (shorted, IHF A-weighted) MM > 70 dB (shorted, unweighted) MC > 67 dB (shorted, IHF A-weighted) MC > 55 dB (shorted, unweighted) |
| Phono Stage Sensitivity / Input Impedance |
MM: 38 dB / 47 k Ω MC: 52 dB / 47 k Ω or 100 Ω |
| Input Impedance |
Unbalanced: 24 k Ω Balanced: 100 k Ω per leg |
|
Preamplifier Output Impedance |
Unbalanced: 100 Ω Balanced: 470 Ω per leg |
| High & Low Pass Crossover Slope | 12 dB per octave |
|
Supported DAC Sampling Rates |
USB: up to 384 kHz / 32-bit PCM DSD Native: DSD 64, DSD 128, DSD 256 DSD over PCM (DoP) at 384 kHz Coax/Optical: up to 192 kHz / 24-bit PCM |
| Digital to Analog Converter |
ESS Sabre32 Reference ES9018K2M 384 kHz / 32-bit |
| USB 2.0 Controller |
Savitech SA9227, 384 kHz / 32-bit |
| Headphone Amplifier |
Texas Instruments TPA6120A Output Impedance 10 ohms |
| XLR Pin Identification |
1 = Ground (Shield) 2 = Positive 3 = Negative (Return) |
| Dimensions |
Width: 17-1/4" (437 mm) Depth: 15" (381 mm) Depth, with cables 17" (432 mm) Height, with feet: 4-1/8" (105 mm) Height, without feet: 3-1/2" (89 mm), 2U |
| Net Weight |
14 lb. (6.3 kg) |
| Power Requirement |
Standby: 0.5 watts Power On: 15 watts 100-250 VAC 50/60 Hz (automatic)10 Hz - 100 kHz, +0/-3 dB 20 Hz - 20 kHz, +0/-0.5 dB |
| XLR Pin Identification | 1 = Ground (Shield) 2 = Positive 3 = Negative (Return) |
| Dimensions |
Width: 17-1/4" (437 mm) Depth: 15"-1/4" (388 mm) Depth, with cables 17" (432 mm) Height, with feet: 4-1/8" (105 mm) Height, without feet: 3-1/2" (89 mm), 2U |
| Net Weight |
27 lb. (12.2 kg) |
| Power requirements |
Standby: <1 Watt Idle (no music playing): 75 Watts Typical Listening levels: 125 Watts Maximum: 800 Watts 110-125 VAC 60 Hz or 220-250 VAC 50 Hz AC mains voltage is set on rear panel |
