From the house of Ooberpad announces the availability of Parasound Halo JC 5 Stereo Power Amplifier by John Curl. The Halo JC 5 is Parasound's new, ultra-high performance, 400 watts per channel, Class A/AB, stereo power amplifier and is the latest achievement of Parasound engineering in concert with legendary audio equipment designer John Curl. Parasound's Halo JC 5 stereo amplifier is a stately, dynamic and extremely musical. John Curl’s signature appears discreetly on its front panel honouring his significant role in its development. The JC 5 will appeal to everyone’s aural senses and fit into the budget brackets of audiophiles and cinephiles alike. With stellar performance and high value, JC 5 is the new amplifier benchmark.
Warranty
1-year manufacturer's warranty
Key Features:
- Circuitry designed by legendary John Curl
- Ultra-high bias Class A/AB operation
- 12 watts per channel of pure Class A power
- 90 amperes peak current per channel
- Stable with speaker impedance dips to 1.5 Ω
- Balanced inputs with discrete circuits
- CHK Infinium, custom 5-way speaker binding posts
- Neutrik locking XLR input connectors
- Vampire gold-plated RCA input & loop output jacks
- Direct-coupled signal path, no capacitors or inductors
- DC Servo and relay protection circuits
- AC turn-on inrush surge protection with relay bypass
- Dual-mono input stages with ±110 volt DC rails
- JFET input stage, MOSFET driver stage
- 24 beta-matched 15 ampere, 60 MHz bipolar output transistors
- 1.7 kVA shielded toroid power transformer with independent windings for each channel
- Independent power supplies for left & right channel input stages, driver stages, output stages
- 8,880 µF Nichicon Gold Tune filter capacitors for input stages
- 132,000 µF Rubycon filter capacitors for output stages
- Full power is rated all the way down to 5Hz for unrestricted low-end bass
- Harris hyper-fast soft-recovery bridge diode rectifiers
- Automatic turn-on by 12 V trigger or audio sensing
- 4 rack space chassis with rear carry handles
- Rack mount hardware is included
Benefits of Parasound Halo JC 5 Stereo Power Amplifier by John Curl:
The Substance Matters
John Curl and Parasound’s engineers insist that what’s inside the JC 5 is even more exquisite than its exterior. Power amplifiers must eliminate input stage distortion in order to avoid output stage distortion which is especially irritating to a listener. In typical power amplifiers, the input and output stages share the same power supply. When driven hard their output stages’ voltage will sag, dragging down the input stage voltage that’s important for cutting down any perceptible distortion. A signature feature of the JC 5 (and JC 1) is a separate independent input stage power supply for each channel that is always 10 volts higher than the output stage voltage. Maintaining input stage voltage attenuates distortion even under the harshest or hostile conditions.
High Current is Imperative to Optimal Performance
High current is crucial for uncompromised sound. The JC 5 output (current) stage uses 24 Sanken 15A output transistors, carefully hand-matched for maximum performance. Their 60MHz bandwidth eliminates slew-rate distortion that robs music of its nuances. They function in pure Class A up to 12 watts per channel, eliminating distortion that blurs music at lower audio levels. Eliminating noise at the input stage is also critical. The JC 5 uses rare Toshiba 2SJ74 J-FETs which are highly coveted for their ultra-low noise.
Nuanced and Uncompromising in the Sound Quality
Every part within JC 5 is meticulously picked for its precision, sound quality and long life. Its speaker terminals are new, developed in collaboration with CHK. Their ample size and wide spacing accommodate even the largest gauge speaker wire or spade connectors. Top-notch quality 24 K gold-plating on the speaker terminals, input connectors and internal audio signal connections assure sound quality that won’t be compromised by corrosion.
Where to buy?
Buy Parasound Halo JC 5 Stereo Power Amplifier by John Curl online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.
Technical Specifications of Parasound Halo JC 5 Stereo Power Amplifier:
| Brand & Model # | Parasound Halo JC 5 |
|
Power Output
|
400 watts x 2, 8 Ω 600 watts x 2, 4 Ω |
| Power Output – Bridged Mode | 1200 watts x 1, 8 Ω Bridged 4 Ω operation is not recommended |
|
|
0.05% THD, RMS continuous power, full audio band (20 Hz - 20 kHz) |
|
|
25 Watts, bias switch set to high 10 Watts, bias switch set to low |
| Current Capacity |
90 amps, peak, per channel |
| Slew Rate |
> 130 volts per microsecond |
| Frequency Response |
5 Hz - 100 kHz, +0/-3 dB 20 Hz - 20 kHz, +0/-0.25 dB |
| Total Harmonic Distortion (THD) |
< 0.05 % at full power < 0.03 % at typical listening levels |
| IM Distortion | < 0.04 % |
| TIM | Unmeasurable |
| Inter-channel Crosstalk | > 87 dB at 1 kHz > 72 dB at 20 kHz |
| Damping Factor | 1000 at 20 Hz |
| Input Impedance |
Unbalanced: 33 kΩ Balanced: 66 kΩ,(33 kΩ per leg) |
| S/N Ratio, inputs shorted |
>122 dB, IHF A-weighted, bias set to Low >120 dB, IHF A-weighted, bias set to High >113 dB, Unweighted, bias set to Low >111 dB, Unweighted, bias set to High |
| Total Gain | 29 dB |
|
Input Sensitivity for 28.28 V Output into 8 Ω |
Unbalanced: 1 V |
| S/N Ratio |
> 116 dB, input shorted, IHF A-weighted > 111 dB, input shorted, unweighted |
|
DC Trigger Requirements |
+9 Vdc to +12 Vdc, 5 mA |
|
Audio Trigger Requirements |
2 mV - 10 mV |
| XLR Pin Identification |
1 = Ground (Shield) |
| Dimensions |
Width: 17-5⁄8" (448 mm) |
| Net Weight |
73 lb. (33.1 kg) |
|
Power Requirement
|
Standby: 1 Watt |
