About
Ooberpad presents the power-packed MSB Technology The Select Headphone Amplifier. With a wide array of headphone choices, it is only possible to achieve the best performance with a single headset in mind. You can not use the universal headphone amp concept with the Select level of performance. That is why MSB Technology has constructed a dedicated Stax* headphone amp to be paired with the Select DAC.
Warranty
1-year manufacturer's warranty
Key Features:
- The Electrostatic Headphone Amplifier
- CNC billet chassis
- Analog bypass
- Anodized finish
Benefits of MSB Technology The Select Headphone Amplifier:
Integrated System
The Select Headphone Amplifier has been designed to take advantage of the powerful DAC outputs. This allows it to achieve a level of headphone playback never heard.
Analog bypass
If you are sharing the headphones with a two-channel system, use an internal bypass in the amp. Simply turn off the unit for the signal to be sent to your other system.
Equalization module
A discrete passive equalization module slot is included with the amp. This allows for slight analog adjustments of the amplifier to accommodate new headphone designs in the future. This can also be used to tune the system for your preferences.
Anodized finishes
Elegant yet commanding, our finishes are available in a matte silver or matte black anodize. Our products include our in-house designed viton feet, but any audiophile M6X1 foot can be installed to personalize your system.
The 12V Trigger Adapter
The 12V trigger adapter provides a multitude of ways for connecting your MSB product with other 12V trigger systems.
Where to buy?
Buy MSB Technology The Select Headphone Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you all the support you need to take the right buying decision in India.
Technical Specifications of MSB Technology The Select Headphone Amplifier:
| Brand & Model # | The Select Headphone Amp |
| Dynamic Range | >140 dB |
| Frequency Response | 5Hz-20Khz, ±0.8dB |
| XLR Input | 75Ω Balanced 4Vrms Maximum |
| Common Mode Rejection Ratio | > 120dB CMRR @ 60Hz > 90dB CMRR @ 1kHz > 70dB CMRR @ 20kHz |
| Crosstalk | <-90dB Crosstalk @ 1kHz <-65dB Crosstalk @ 20kHz |
| XLR Output | Direct connection to input when enabled or unit powered off. When listening to headphones, output is muted with 75Ω output impedance |
| Headphone Output | 1x Stax style output |
| Bias Voltage | 580Vdc, 5 MΩ |
| Controls | IR Remote (Configurable) Power Button (Configurable) 2x MSB 12V Trigger |
| Power Consumption | 80W Less than 2W standby |
| Topology | |
| Input/Gain Stage | - Class-A - Quad balanced - Impedance matched - Transformer coupled - Fully discrete |
| Output Stage | - High Voltage Electrostatic Class-A - Balanced |
| Chassis Dimensions | |
| Width: | 17.5 in (444 mm) |
| Depth: | 17.5 in (444 mm) |
| Height: | 2.75 in (70 mm) |
| Weight: | 38 lbs (17 kg) |
| Product Feet: | M6X1 Thread |
| Included Accessories |
User manual Ground cable IEC power cord |
